Automatic Shrink Sleeve Labeling Machine

Automatic shrink sleeve machine is used for shrink PVC labels on bottles/caps,it includes shrink label machine/shrink tunne/steam generator. The bottles after put labels it will go to shrink tunnel,the steam generator supply steam to shrink tunnel for shrinking.
  • Item NO.:

    EPSL240
  • Order(MOQ):

    1
  • Product Origin:

    China
  • Shipping Port:

    Xiamen
  • Power:

    2.8kw
  • Available Size:

    Length:20~260mm
  • Dimensions:

    Length:5000mm; Width:1050mm.
  • Weight:

    300kg


Fully automatic sleeve label machines are used in automated production lines with high production volumes. An integration into existing production lines - both hardware and software - should be possible. If a high cycle rate of the production line is required, fully automated labeling of the products and packaging is necessary. Fully automatic shrink sleeve labeling systems are less personnel-intensive.

Automatic Shrink Sleeve Labeling Machine

Automatic Bottle Sleeving Labeling Machine is produced by E-pack technology Co.ltd, Automatic Bottle Sleeve Labeling Machine with Steam tunnel and Steam Generator, adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; it adopts the positioning mould to ensure the casting label precise, rapid and stable.It is design for the inserting PVC label on the drinking bottle with steam shrinking tunnel and electrical heating tunnel.

sleeve label machine

shrink sleeve applicator machine

CHARACTERISTICS

1.Features

  • High Stability of the mechanical structure. Wholeframework of the overall use of stainless steel, solidand stainless.
  • Aprotective cover and man-machine interfaceoperating system, the whole machine operates morehuman-based, more simple control and use.
  • The machine can be worked with the whole production line and fully operated with the whole vline.
  • Unique knife plate design, within the scope of ourspecification, can avoid changing it.
  • Forced sleeve-label style, very economical.
  • Overall rotation system, can be linked to adjustment, suitable forr various label rolls'specification.
  • Lnner dianeter of the label roll: 5"-10", can beadjusted differently.

2.After-sale service

  • One year warranty. Under warranty, if following the introductions during the use, any damage to the parts of the machine, we will provide free maintenance service or free replacement, and freight costs are requested
  • After the warranty period, we continue to provide lifetime maintenance services.

MAIN ELECTRICAL CONFIGURATION

(Remark: The configuration will base on the materials condition to adjust it into the same level’s configuration and we also can accord customers’ requirement to revise).

Electrical System

Name

Brand

Qty

Name

Brand

Q’ty

PLC

Panasonic

1set

Traction motor

BALE/YAKO

2sets

Label sensor

LEUZE/SICK

2sets

HMI

WEINVIEW

1set

Product sensor

Panasonic

1set

Run the motor

CHEEMING

2set

Steam generator

24/36KW

1set







Mechanism Parts

Name

 Material

Qty

Name

 Material

Q’ty

Feeding mechanism

Stainless steel, Aluminum alloy

1set

Bid sending and cutter head mechanism

Steel, Aluminum alloy, Armoring

1set

Conveying mechanism

Stainless steel, Aluminum alloy

1set

Electric box mechanism

Stainless steel, Aluminum alloy

1set

Bottle parting and guide

Stainless steel, Aluminum alloy

2sets

Rack

Stainless steel, Aluminum alloy

1set

Shrink oven

Stainless steel,Steam Oven

1set

Center conductor post

Stainless steel,POM

1set

TECHNICAL SPECIFICATIONS

Capacity

About 0-200P/min(Related to product, label size)

Accuracy

±1mm(Excluding product and label error)

Application product size

Diameter:φ25mm~φ110mm;

Height:30mm~280mm;

Applicable label size

Length:20~260mm

Maximum label supply

Outer diameter:≤500;

Inner diameter:≤76mm;

Environment temperature/humidity

0-50℃/15-85%

Voltage

AC220/380V,50HZ

Dimensions

Length:5000mm

Width:1050mm

Weight

300Kg

APPLICATIONS

Automatic sleeving labeling machine is suitable for kinds of bottle types, like: round bottle, square bottle, flat bottle, curve bottle and cup-shaped. We always can meet your all kind of requirement no matter it is for cap or bottle. The machine is suitable for pharmaceutical, food industries, health-food, medicine, juice, milk, drink...etc.

shrink sleeve labeling
